11V 900RPM DC Brush Gear Motor with gearbox 9.4W
Specifications
| Product Name | Dc Brush Gear Motor |
| Torque | 0.1 NM |
| Commutation | Brush |
| Speed(RPM) | 900 |
| Continuous Current(A) | 1.5A |
| Dielectric Strength | 500V AC 1minute |
| Ambient Temperature | -20℃-50℃ |
| Max Radial load | ≤45N (10mm from front flange) |
| Shaft axial load | ≤25N |
| Reduction Ratio | 12:1 |
| Gearbox Housing Material | Zinc alloy |
| Backlash at no-load | ≤1.5 |
| Gearbox rated tolerance torque | 0.3NM |
| Bearing at output | Ball bearing |
Product Description
11V 900RPM DC Brush Gear Motor with gearbox 9.4W
A brushed DC motor from Hetai is ideal for portable and small devices. Brush DC motor technology offers the distinct advantages of low friction, low starting voltages, absence of iron losses, high efficiency, good thermal dissipation and linear torque-speed function. 36PG gearbox used a zinc alloy gearbox, which is also more cost-effective compare to powder metallurgy gearbox.
In addition, Our brushed DC motors are designed for quick and easy modification, so you can get exactly. We can customize standard brush motor features to meet specific application requests, including performance specifications, mounting configuration, thermal and ambient condition requirements, and other operational needs.
Electrical Specification
| Model | 36 Brush gear motor |
| Voltage （V） | 11V |
| Rated Torque with gearbox （N.M） | 0.1~0.3 N.m |
| Speed (rpm) | 900 |
| Motor SIze（mm） | 36*36*88 mm |
Mechanical Dimension
Gearbox specification
36mm Zinc Alloy
|
Housing material |
Bearing at output |
Radial load(10mm from flange)N |
Shaft axial load(N) |
Shaft press-fit force max(N) |
Radial play of shaft(mm) |
Thrust play of shaft(mm) |
Backlash at no-load (°) |
|
Zinc alloy |
Porous bearings |
≤45 |
≤25 |
≤100 |
≤0.08 |
≤0.4 |
≤1.5 |
|
Reduction ratio |
Rated tolerance torque (Nm) |
Max momentary tolerance torque (Nm) |
Efficiency% |
Length (mm) |
Weight(g) |
Number of gear trains |
|
1/12 |
0.3 |
1.0 |
81% |
26.8 |
100 |
1 |
